rama

Model	R.S.W.	3KVA	5KVA	7.5KVA

Prime Voltage	V	220/440	220/440	220/440
Ph.	No.	1/2	1/2	1/2
Cooling		------------------- Natural Air cooled ----------------
Range of Welding	Rotary Switch	------------------- 8 Steps ----------------
Timer Delay Relay		Yes	Yes	Yes
Recomended Gages	mm	.071	1.21	1.66
Max Interim weld current at 60% cycle	KVA	3	5	7.5
Body Size Height	inch	38	40	45
Timer connector pnematic moter	on Request	-	-	-

Model	R.S.W.	10KVA	15KVA	20KVA

Prime Voltage	V	220/440	220/440	220/440
Ph.	No.	1/2	1/2	1/2
Cooling		------------------- Natural Air cooled ----------------
Range of Welding	Rotary Switch	------------------- 8 Steps ----------------
Timer Delay Relay		Yes	Yes	Yes
Recomended Gages	mm	2.64	3.25	4.1
Max Interim weld current at 60% cycle	KVA	10	15	20
Body Size Height	inch	50	52	54
Timer connector pnematic moter	on Request	-	-	-

SHREE RAMA IMPEX
